Description
True UPS: by-pass switch, 14ms
Integrated Solar MPPT accepts up to 800W solar charge from 13V – 45V, max 12A.
All charging cables and connectors included as accessory (AC and solar).
Expandable capacity: increase capacity by adding up to 6 extra batteries (2.5kWh each) up to 17.5kWh optional. Extra batteries are not included and must be purchased separately.
Specifications
| Battery Service Life | 10 years’ service life +/- |
| Battery Chemistry | Square Aluminum Case Lithium Iron Phosphate, LiFePO4. |
| Battery capacity | 2560 Wh (expandable to 17.5kWh) |
| AC Output | 3000W total (5000W peak), 230V 50Hz, 16A, Pure Sine |
| DC Output | 1 x 12,6V/30A regulated, Anderson PP30
1 X 12.6V/10A, regulated, CLA 2 x 12.6V/3A regulated, DC5521 (barrel plug) 2 x USB-A Fast Charge 5V/2.4A, 18W per port 2 x USB-A Fast Charge 5V/2.4A, 12W per port 2 x type C, PD 100W per port |
| Input sources to re-charge | AC230V, 2300W fast charge, 90 minutes +/-
Solar PV max. 800W, 13V-25V, max. 12A (MPPT) |
| UPS | Yes, 14ms switching time |
| Indicators | Full LCD display for vital system info |
| Weight | 33kg |
| Dimensions | 536 * 270 * 321 mm |
| Safety | Short Circuit
Over-Current Over-Voltage Low-Voltage Over-Load Over-Temperature |
| Accessory | 1 x AC charger cable
1 x Solar cable with Anderson SB50 grey User manual |
| Operating Range | 0°C to 45°C |
| Warranty | 2 Years |
| Certification | CE, FCC, RoHS, PSE |
| App | Yes, Open Source, compatible with Alexa and Google |
